COMPACTOR

Functions



Features

  • Strong compact throughout high frequency and power.
  • Air vibration absorber minimize operator’s fatigue.
  • Dual performance of steel pile drive and soil compact
  • High efficiency performance with hydraulic piston motor
  • Diverse job applicable : ground compaction, building ground work, slope compact, backfill construction.

Specifiaction

Model Unit KCM04 KCM06 KCM08 KCM10
4 – 10 Ton 10 – 17 Ton 17 – 24 Ton 24 – 30 Ton
Hardening force ton 4.0 6.5 15 15
Frequency of vibration rpm 2000 2000 2000 2000
Using flow l/min 45-75 85-105 120-170 120-170
Pressure force kg/cm2 100-130 100-130 150-200 150-200
Weight kg 300 500 900 950
Bottom plaste size mm 900×550×25 1160×700×28 1350×900×30 1350×900×30
Height mm 760 920 1060 1100
Width mm 550 700 900 900
Application excavator ton 4 ~ 10 10 ~ 17 17 ~ 24 24 ~ 30

* The specifications of this equipment are subject to change for improvements.
